标题 |
规格书 |
IF(A) |
VRRM(V) |
IFSM(A) |
VF(V) |
@IF(A) |
IR@25℃(uA) |
trr(ns) |
OUTLINE |
|---|---|---|---|---|---|---|---|---|---|
| SR30200LD1 | 下载 | 30.0 | 200 | 250 | 0.88 | 15.0 | 20 | TO-263(D2PAK) | |
| SR30200SLCT | 下载 | 30.0 | 200 | 250 | 0.85 | 15.0 | 20 | TO-220AB | |
| SRF30200SLCT | 下载 | 30.0 | 200 | 250 | 0.85 | 15.0 | 20 | ITO-220AB | |
| SR30200SLD1 | 下载 | 30.0 | 200 | 250 | 0.85 | 15.0 | 20 | TO-263(D2PAK) | |
| SR4045LCT | 下载 | 40.0 | 45 | 350 | 0.55 | 20.0 | 200 | TO-220AB | |
| SRF4045LCT | 下载 | 40.0 | 45 | 350 | 0.55 | 20.0 | 200 | ITO-220AB | |
| SR4045LD1 | 下载 | 40.0 | 45 | 350 | 0.55 | 20.0 | 200 | TO-263(D2PAK) | |
| SR4060LCT | 下载 | 40.0 | 60 | 350 | 0.56 | 20.0 | 150 | TO-220AB | |
| SRF4060LCT | 下载 | 40.0 | 60 | 350 | 0.56 | 20.0 | 150 | ITO-220AB | |
| SR4060LD1 | 下载 | 40.0 | 60 | 350 | 0.56 | 20.0 | 150 | TO-263(D2PAK) | |
| SR4060LKT | 下载 | 40.0 | 60 | 300 | 0.56 | 20.0 | 150 | TO-3P | |
| SR4060SLCT | 下载 | 40.0 | 60 | 350 | 0.56 | 20.0 | 150 | TO-220AB | |
| SRF4060SLCT | 下载 | 40.0 | 60 | 350 | 0.56 | 20.0 | 150 | ITO-220AB | |
| SR4060SLD1 | 下载 | 40.0 | 60 | 350 | 0.56 | 20.0 | 150 | TO-263(D2PAK) | |
| SR4080LCT | 下载 | 40.0 | 80 | 300 | 0.68 | 20.0 | 100 | TO-220AB | |
| SRF4080LCT | 下载 | 40.0 | 80 | 300 | 0.68 | 20.0 | 100 | ITO-220AB | |
| SR4080LD1 | 下载 | 40.0 | 80 | 300 | 0.68 | 20.0 | 100 | TO-263(D2PAK) | |
| SR40100LCT | 下载 | 40.0 | 100 | 350 | 0.76 | 20.0 | 60 | TO-220AB | |
| SRF40100LCT | 下载 | 40.0 | 100 | 350 | 0.76 | 20.0 | 60 | ITO-220AB | |
| SR40100LD1 | 下载 | 40.0 | 100 | 350 | 0.76 | 20.0 | 60 | TO-263(D2PAK) |
