标题 |
规格书 |
IF(A) |
VRRM(V) |
IFSM(A) |
VF(V) |
@IF(A) |
IR@25℃(uA) |
trr(ns) |
OUTLINE |
|---|---|---|---|---|---|---|---|---|---|
| SR40100LD1 | 下载 | 40.0 | 100 | 350 | 0.76 | 20.0 | 60 | TO-263(D2PAK) | |
| SR40120LCT | 下载 | 40.0 | 120 | 300 | 0.74 | 20 | 50 | TO-220 | |
| SRF40120LCT | 下载 | 40.0 | 120 | 300 | 0.74 | 20 | 50 | ITO-220 | |
| SR40120LD1 | 下载 | 40.0 | 120 | 300 | 0.74 | 20 | 50 | TO-263 | |
| SR40150LCT | 下载 | 40.0 | 150 | 300 | 0.90 | 20.0 | 10 | TO-220AB | |
| SR40150LD1 | 下载 | 40.0 | 150 | 300 | 0.90 | 20.0 | 10 | TO-263(D2PAK) | |
| SRF40150LCT | 下载 | 40.0 | 150 | 300 | 0.90 | 20.0 | 10 | ITO-220AB | |
| SR40200LCT | 下载 | 40.0 | 200 | 400 | 0.90 | 20.0 | 20 | TO-220AB | |
| SRF40200LCT | 下载 | 40.0 | 200 | 400 | 0.90 | 20.0 | 20 | ITO-220AB | |
| SR40200LD1 | 下载 | 40.0 | 200 | 400 | 0.90 | 20.0 | 20 | TO-263(D2PAK) | |
| SR40200LPT | 下载 | 40.0 | 200 | 400 | 0.90 | 20.0 | 20 | TO-247AB | |
| SR6045LCT | 下载 | 60.0 | 45 | 400 | 0.58 | 30.0 | 100 | TO-220AB | |
| SRF6045LCT | 下载 | 60.0 | 45 | 400 | 0.58 | 30.0 | 100 | ITO-220AB | |
| SR6045LD1 | 下载 | 60.0 | 45 | 400 | 0.58 | 30.0 | 100 | TO-263(D2PAK) | |
| SR6080LCT | 下载 | 60.0 | 80 | 300 | 0.65 | 30.0 | 100 | TO-220AB | |
| SRF6080LCT | 下载 | 60.0 | 80 | 300 | 0.65 | 30.0 | 100 | ITO-220AB | |
| SR6080LD1 | 下载 | 60.0 | 80 | 300 | 0.65 | 30.0 | 100 | TO-263 | |
| SR60100LCT | 下载 | 60.0 | 100 | 300 | 0.80 | 30.0 | 50 | TO-220AB | |
| SRF60100LCT | 下载 | 60.0 | 100 | 300 | 0.80 | 30.0 | 50 | ITO-220AB | |
| SR60100LD1 | 下载 | 60.0 | 100 | 300 | 0.80 | 30.0 | 50 | TO-263(D2PAK) |
