标题 |
规格书 |
IF(A) |
VRRM(V) |
IFSM(A) |
VF(V) |
@IF(A) |
IR@25℃(uA) |
trr(ns) |
OUTLINE |
|---|---|---|---|---|---|---|---|---|---|
| ABS6 | 下载 | 1.0 | 600 | 35 | 1.1 | 1.0 | 5 | ABS | |
| ABS8 | 下载 | 1.0 | 800 | 35 | 1.1 | 1.0 | 5 | ABS | |
| ABS10 | 下载 | 1.0 | 1000 | 35 | 1.1 | 1.0 | 5 | ABS | |
| MB1S | 下载 | 1.0 | 100 | 35 | 1.0 | 1.0 | 5 | MBS | |
| MB2S | 下载 | 1.0 | 200 | 35 | 1.0 | 1.0 | 5 | MBS | |
| MB4S | 下载 | 1.0 | 400 | 35 | 1.0 | 1.0 | 5 | MBS | |
| MB6S | 下载 | 1.0 | 600 | 35 | 1.0 | 1.0 | 5 | MBS | |
| MB8S | 下载 | 1.0 | 800 | 30 | 1.0 | 1.0 | 5 | MBS | |
| MB10S | 下载 | 1.0 | 1000 | 35 | 1.0 | 1.0 | 5 | MBS | |
| MB2F | 下载 | 1.0 | 200 | 35 | 1.1 | 1.0 | 5 | MBF | |
| MB4F | 下载 | 1.0 | 400 | 35 | 1.1 | 1.0 | 5 | MBF | |
| MB6F | 下载 | 1.0 | 600 | 35 | 1.1 | 1.0 | 5 | MBF | |
| MB8F | 下载 | 1.0 | 800 | 35 | 1.1 | 1.0 | 5 | MBF | |
| MB10F | 下载 | 1.0 | 1000 | 35 | 1.1 | 1.0 | 5 | MBF | |
| DB101 | 下载 | 1.0 | 50 | 45 | 1.1 | 1.0 | 5 | DB | |
| DB102 | 下载 | 1.0 | 100 | 45 | 1.1 | 1.0 | 5 | DB | |
| DB103 | 下载 | 1.0 | 200 | 45 | 1.1 | 1.0 | 5 | DB | |
| DB104 | 下载 | 1.0 | 400 | 45 | 1.1 | 1.0 | 5 | DB | |
| DB105 | 下载 | 1.0 | 600 | 45 | 1.1 | 1.0 | 5 | DB | |
| DB106 | 下载 | 1.0 | 800 | 45 | 1.1 | 1.0 | 5 | DB |
