标题 |
规格书 |
IF(A) |
VRRM(V) |
IFSM(A) |
VF(V) |
@IF(A) |
IR@25℃(uA) |
trr(ns) |
OUTLINE |
|---|---|---|---|---|---|---|---|---|---|
| FR201 | 下载 | 2.0 | 50 | 60 | 1.2 | 2.0 | 5 | 150 | DO-15 |
| FR202 | 下载 | 2.0 | 100 | 60 | 1.2 | 2.0 | 5 | 150 | DO-15 |
| FR203 | 下载 | 2.0 | 200 | 60 | 1.2 | 2.0 | 5 | 150 | DO-15 |
| FR204 | 下载 | 2.0 | 400 | 60 | 1.2 | 2.0 | 5 | 150 | DO-15 |
| FR205 | 下载 | 2.0 | 600 | 60 | 1.2 | 2.0 | 5 | 250 | DO-15 |
| FR206 | 下载 | 2.0 | 800 | 60 | 1.2 | 2.0 | 5 | 500 | DO-15 |
| FR207 | 下载 | 2.0 | 1000 | 60 | 1.2 | 2.0 | 5 | 500 | DO-15 |
| FR201G | 下载 | 2.0 | 50 | 60 | 1.3 | 2.0 | 5 | 150 | DO-15 |
| FR202G | 下载 | 2.0 | 100 | 60 | 1.3 | 2.0 | 5 | 150 | DO-15 |
| FR203G | 下载 | 2.0 | 200 | 60 | 1.3 | 2.0 | 5 | 150 | DO-15 |
| FR204G | 下载 | 2.0 | 400 | 60 | 1.3 | 2.0 | 5 | 150 | DO-15 |
| FR206G | 下载 | 2.0 | 800 | 60 | 1.3 | 2.0 | 5 | 500 | DO-15 |
| FR205G | 下载 | 2.0 | 600 | 60 | 1.3 | 2.0 | 5 | 250 | DO-15 |
| FR207G | 下载 | 2.0 | 1000 | 60 | 1.3 | 2.0 | 5 | 500 | DO-15 |
| RS2A | 下载 | 2.0 | 50 | 50 | 1.3 | 2.0 | 5.0 | 150 | SMA |
| RS2G | 下载 | 2.0 | 400 | 50 | 1.3 | 2.0 | 5.0 | 150 | SMA |
| RS2J | 下载 | 2.0 | 600 | 50 | 1.3 | 2.0 | 5.0 | 250 | SMA |
| RS2K | 下载 | 2.0 | 800 | 50 | 1.3 | 2.0 | 5.0 | 500 | SMA |
| RS2M | 下载 | 2.0 | 1000 | 50 | 1.3 | 2.0 | 5.0 | 500 | SMA |
| RS2AS | 下载 | 2.0 | 50 | 50 | 1.3 | 2.0 | 5 | 150 | SMAF |
