标题 |
规格书 |
IF(A) |
VRRM(V) |
IFSM(A) |
VF(V) |
@IF(A) |
IR@25℃(uA) |
trr(ns) |
OUTLINE |
|---|---|---|---|---|---|---|---|---|---|
| RGP10M | 下载 | 1.0 | 1000 | 30 | 1.3 | 1.0 | 5.0 | 500 | DO-41 |
| RS1A | 下载 | 1.0 | 50 | 30 | 1.3 | 1.0 | 5.0 | 150 | SMA |
| RS1G | 下载 | 1.0 | 400 | 30 | 1.3 | 1.0 | 5.0 | 150 | SMA |
| RS1J | 下载 | 1.0 | 600 | 30 | 1.3 | 1.0 | 5.0 | 250 | SMA |
| RS1K | 下载 | 1.0 | 800 | 30 | 1.3 | 1.0 | 5.0 | 500 | SMA |
| RS1M | 下载 | 1.0 | 1000 | 30 | 1.3 | 1.0 | 5.0 | 500 | SMA |
| R1A | 下载 | 1.0 | 50 | 30 | 1.3 | 1.0 | 5.0 | 150 | SOD-123FL |
| R1G | 下载 | 1.0 | 400 | 30 | 1.3 | 1.0 | 5.0 | 150 | SOD-123FL |
| R1J | 下载 | 1.0 | 600 | 30 | 1.3 | 1.0 | 5.0 | 250 | SOD-123FL |
| R1K | 下载 | 1.0 | 800 | 30 | 1.3 | 1.0 | 5.0 | 500 | SOD-123FL |
| R1M | 下载 | 1.0 | 1000 | 30 | 1.3 | 1.0 | 5.0 | 500 | SOD-123FL |
| F1 | 下载 | 1.0 | 50 | 30 | 1.3 | 1.0 | 5.0 | 150 | SOD-123FL |
| F4 | 下载 | 1.0 | 400 | 30 | 1.3 | 1.0 | 5.0 | 150 | SOD-123FL |
| F5 | 下载 | 1.0 | 600 | 30 | 1.3 | 1.0 | 5.0 | 250 | SOD-123FL |
| F6 | 下载 | 1.0 | 800 | 30 | 1.3 | 1.0 | 5.0 | 50 | SOD-123FL |
| F7 | 下载 | 1.0 | 1000 | 30 | 1.3 | 1.0 | 5.0 | 500 | SOD-123FL |
| RS1AS | 下载 | 1.0 | 50 | 30 | 1.3 | 1.0 | 5.0 | 150 | SMAF |
| RS1BS | 下载 | 1.0 | 100 | 30 | 1.3 | 1.0 | 5.0 | 150 | SMAF |
| RS1DS | 下载 | 1.0 | 200 | 30 | 1.3 | 1.0 | 5.0 | 150 | SMAF |
| RS1GS | 下载 | 1.0 | 400 | 30 | 1.3 | 1.0 | 5.0 | 150 | SMAF |
