标题 |
规格书 |
IF(A) |
VRRM(V) |
IFSM(A) |
VF(V) |
@IF(A) |
IR@25℃(uA) |
trr(ns) |
OUTLINE |
|---|---|---|---|---|---|---|---|---|---|
| SRF20100SLCT | 下载 | 20.0 | 100 | 300 | 0.65 | 10.0 | 50 | ITO-220AB | |
| SR20100SLD1 | 下载 | 20.0 | 100 | 300 | 0.65 | 10.0 | 50 | TO-263(D2PAK) | |
| SP20U100L | 下载 | 20.0 | 100 | 150 | 0.75 | 20.0 | 100 | TO-277 | |
| SR20100L | 下载 | 20.0 | 100 | 200 | 0.75 | 20.0 | 50 | TO-220AC | |
| SRF20100L | 下载 | 20.0 | 100 | 200 | 0.75 | 20.0 | 50 | ITO-220AC | |
| SR20100SLM3 | 下载 | 20.0 | 100 | 250 | 0.73 | 20.0 | 50 | TO-252(DPAK) | |
| SR20120LCT | 下载 | 20.0 | 120 | 200 | 0.85 | 10.0 | 50 | TO-220AB | |
| SRF20120LCT | 下载 | 20.0 | 120 | 200 | 0.85 | 10.0 | 50 | ITO-220AB | |
| SR20120LD1 | 下载 | 20.0 | 120 | 200 | 0.85 | 10.0 | 50 | TO-263(D2PAK) | |
| SR20120SLCT | 下载 | 20.0 | 120 | 250 | 0.75 | 10 | 50 | TO-220AB | |
| SRF20120SLCT | 下载 | 20.0 | 120 | 250 | 0.75 | 10 | 50 | ITO-220AB | |
| SR20120SLD1 | 下载 | 20.0 | 120 | 250 | 0.75 | 10 | 50 | TO-263 | |
| SR20150LCT | 下载 | 20.0 | 150 | 200 | 0.88 | 10.0 | 20 | TO-220AB | |
| SRF20150LCT | 下载 | 20.0 | 150 | 200 | 0.88 | 10.0 | 20 | ITO-220AB | |
| SR20150LD1 | 下载 | 20.0 | 150 | 200 | 0.88 | 10.0 | 20 | TO-263(D2PAK) | |
| SR20150LM3 | 下载 | 20.0 | 150 | 200 | 0.85 | 20.0 | 20 | TO-252(DPAK) | |
| SR20200LCT | 下载 | 20.0 | 200 | 250 | 0.90 | 10.0 | 20 | TO-220AB | |
| SR20200LD1 | 下载 | 20.0 | 200 | 250 | 0.90 | 10.0 | 20 | TO-263(D2PAK) | |
| SRF20200LCT | 下载 | 20.0 | 200 | 250 | 0.90 | 10.0 | 20 | ITO-220AB | |
| SR20200LM3 | 下载 | 20.0 | 200 | 200 | 0.90 | 20.0 | 20 | TO-252(DPAK) |
